BAY-LYNX MULTICAT ADVANTAGE
Bay-lynx is an innovative company which centers on superior quality, and user ease of their Bay-Lynx Multicat Spreaders. They use high grade products and certified welders and technicians to present their customers with the highest quality product possible. The Bay-Lynx Multicat Spreader is the ideal machine to place Sand, Stone, Topsoil, and Mulch in difficult, 'hard to reach' areas such as basements, tile beds, slabs, tanks, and utility trenches, pools and more. The patented Load Suspension Beam along with the plastic liner allows you to evenly unload materials that would normally bridge or hang up in conventional machines. One operator can unload up to 22 tons of material in minutes and reach distances of up to 100' feet from the rear of the truck.
The Bay-lynx Multicat Spreader is used by, Quarry Operators, Haulers, Contractors, Landscapers, and many businesses requiring quick and easy placement of a complete range of products.
Hydraulics
A. High Speed Throw Conveyer has its own dedicated Pump Circuit
-
This eliminates "hiccups" in the throw in the throw pattern, when other functions are activated,
-
Allows for 4 cubic inches more displacement,
-
Produces almost twice the output torque,
-
Unit will throw to 100' from rear bumper, with aid of power drive Super Shield.
B. Eliminating flow divider reduces pressure drop in system, increasing efficiency.
C. Using a vane pump instead of the conventional gear pump,
-
-
Eliminates contamination of system,
-
Higher efficiency than gear pumps,
-
Quicker and easier to repair.
Planetary Drive Boom Swing
A. Allows rotation past 90 degrees to right and left,
B. Will maintain full lift of 11', from flat ground, through the full arc of rotation,
C. Greatly reduces maintenance costs.
Feed Conveyor
A. Much cleaner than models using toughing idlers, since the belt cannot pull away from the skirting between rollers allowing spillage of product,
B. 21" wide belt, 17" wide opening, allows 21 tons to be discharges in 4 minutes,
C. The planetary gear reduction drive is inside the head pulley, eliminating the drive coupling, creating a small, neater package.
Patented Load Suspension Beam
A. Allows discharge of bulky materials such as topsoil, sand, road-base, bark, etc. Materials up to 6" diameter can be discharged,
B. Down pressure is limited to prevent damage to the body,
C. Each end is connected directly to cylinder, eliminating the use of pulleys and cables to raise the beam.
Most Advanced Paint Facility in the Industry
A. The Surface is sand blasted before applying two coats epoxy based high-build- primer, and four coats of two-part cross-linked acrylic topcoat,
B. This results in a durable finish that is more resistant to chipping and cracking,
C. To ensure full Quality Control, paint thickness is tested, and evaluated, at twelve locations on the body.
Plastic Box Liner
A. Prevents Material from freezing to the hopper, and provides an abrasive resistant surface,
B. Allows Material to flow more freely with the aid of release agents in the plastic.
Center of Gravity
A. The Bay-Lynx Multicat Spreader boasts the lowest canter of gravity on the Market today. Up to 14" lower than any other spreader.
B. This has been obtained with the help of our well-engineered roller/slide pan main conveyor system, and the robust box and plate sections that fasten the spreader to the chassis rails.
C. Every driver will appreciate that low center of gravity, when pulling heavy loads out of the quarry, up steep hills, around tight corners, and when getting into position on messy and uneven job sites.
THE BAY-LYNX MULTICAT STONE SPREADER IS YOUR #1 CHOICE.
|
